Shireen 4.4~6.0 GHz MIMO Bi-directional Amplifier 40 Watt Output
Estimated shipping time across UK: 1-2 business days via DPD , DHL , Parcel Force, & Fedex
Certified Professional Expertise
Product Overview
Shireen’s low SWaP MIMO bi-directional amplifier delivers 40 Watts output per port in a compact, lightweight design optimized for SDRs, MANET systems, and high-speed RF applications. Covering military frequency bands from 4.4GHz to 6.0GHz, this rugged amplifier features rapid switching technology, high transmit gain for low-power radios, and support for fixed, mobile, aerial, and embedded RF platforms. Its compact form factor and OEM availability make it ideal for tactical and integrated communication systems.
Key Features
Highest Power in Class
Miniature 40 Watt amplifier (each port) is the highest power amplifier configured in its size and weight
Low SWaP Design
Weighs only 10.5 Oz enclosed for size, weight, and power constrained platforms
Rapid Switching Technology
Equipped with latest rapid switching technology at <1 µs for high-speed modulated radios
Military Band Coverage
Offered in military bands of 4.4~5GHz and 5~6 GHz
Manual Switching Option
Manual switching via 3V / 5V TTL for external control flexibility
High Transmit Gain
26 dB Tx gain makes it ideal for low output-power radios
Waveform Compatibility
Compatibility with all modern and emerging MANET waveforms
SDR Optimized
High performance for SDRs and other high-speed modulated, embedded RF platforms
Multiple Platform Support
Ideal for fixed, mobile, and aerial platforms
OEM Availability
Available in OEM packaging for system integrators and developers
Wide Temperature Range
Operates from -40°C to +70°C with appropriate heatsinking
Ultra-Compact Form Factor
4.35" x 3.10" x 0.9" footprint for easy integration
Technical Data
| Parameter | Rating / Detail |
|---|---|
| Product Name | 4.4~6.0 GHz MIMO Bi-directional Amplifier |
| Version | Low SWaP Series |
| Operating Range Version A | 4400 – 5000 MHz |
| Operating Range Version B | 5000 – 6000 MHz |
| Operating Mode | TDD (Time Division Duplex) |
| Transmit Peak Power | 46 dBm (each port) |
| Transmit Gain | 26 dB (+/-1) |
| Transmit Input Power | -4 dBm min, 28 dBm max |
| T/R Switching | Auto switching at <1 µs, or via manual 3V / 5V TTL |
| Receive Gain | 10 dB (+/- 2) |
| Noise Figure | <5 dB |
| LED Indicators | Red for Receive (default mode); Green for Transmit |
| DC Power | 28 VDC (24 to 30 VDC) |
| Power Consumption | With 28 VDC, 60 mA Rx, 3.2 A @ 10 W Tx CW, 4.4 A @ 20 W Tx CW, 6.8 A @ 40 W Tx CW |
| Operating Temperature | -40 °C to + 70 °C (158 °F) with appropriate heatsinking |
| Temperature Sensor | Optional: As per customer needs |
| Dimensions | 4.35" (110.5mm) x 3.10" (78.7mm) x 0.9" (22.9mm) |
| Weight | 10.5 Oz (298g) |
| Enclosure Connector | PT2 Connector |
