Shireen 2.4GHz 20 Watt Outdoor Bi-directional Amplifier
Estimated shipping time across UK: 1-2 business days via DPD , DHL , Parcel Force, & Fedex
Certified Professional Expertise
Product Overview
Shireen’s 2.4GHz 20 Watt outdoor bi-directional amplifier delivers powerful RF amplification in a rugged weatherproof enclosure engineered for demanding outdoor deployments. Designed for compatibility with 802.11b/g wireless radios, this high-efficiency amplifier operates without fans or oversized heat sinks while supporting power-over-coax installations. Ideal for military, OEM, licensed, and specialized wireless applications requiring reliable high-power outdoor performance.
Key Features
Fanless Operation
Does not require a fan or huge heat sink for quiet and reliable operation
High Efficiency
Designed with the latest available components delivering 20Watt output at very high efficiency
Radio Compatibility
Works with all 2.4GHz radios using both 802.11 b or g modes
All-Weather Installation
Packed in an outdoor housing with power over Coax for all weather installations
High RF Power
43 dBm (20 Watt) output for extended range and penetration
Low Noise Figure
2.8 dB noise figure for sensitive receive performance
Gain Flexibility
Standard 20 dB transmit gain with optional 26 dB configuration available
Wide Temperature Range
Operates from -40°C to +65°C
Durable Construction
Weatherproof machined aluminum housing with anodized finish
Complete Outdoor Kit
Includes outdoor amplifier and DC injector
Sales Restriction
Offered only to Military, OEM, Licensed or overseas customers
Technical Data
| Parameter | Rating / Detail |
|---|---|
| Product Name | 2.4GHz 20Watt Amplifier |
| Version | Outdoor unit |
| Operating Range | 2400 - 2500 MHz |
| Operating Mode | TDD, Time Division duplex |
| Transmit Power | 43 dBm, 20 Watt |
| Transmit Gain | 20 dB (26 dB optional) |
| Transmit Input Power | 0 dBm min, 20 dBm max |
| Receive Gain | 18 dB |
| Noise Figure | 2.8 dB |
| LED Indicators | Red for Receive (Default mode), Green for Transmit |
| Power Consumption @ 28 V DC | 55 mA Rx, 1.8A Tx |
| Operating Temp | -40 °C to + 65 °C |
| DC Power | 28 V DC via power over coax, using DC injector |
| Amplifier Dimensions | 3.5" x 6.0" x 1.2" (45.7mm x 104.2mm x 25.4mm) |
| Amplifier Enclosure | Weatherproof, machined aluminum housing with Anodized finish |
| Amplifier Connectors | Type N female |
| Amplifier Weight | 1 lb, 3.0 oz |
| DC Injector Dimensions | 1.4" x 3.5" x 1.0" (with Type N female connectors) |
| DC Injector Enclosure | Machined aluminum housing with Anodized finish |
| DC Injector Connectors | Type N female |
| DC Injector Weight | 4.7 Oz |
