Shireen 2.4GHz 1 Watt Outdoor Amplifier Coax Series
Estimated shipping time across UK: 1-2 business days via DPD , DHL , Parcel Force, & Fedex
Certified Professional Expertise
Product Overview
Shireen’s 2.4GHz outdoor amplifier delivers 1 Watt linear output with up to 2 Watts saturated power in an ultra-compact, weatherproof coaxial housing. Designed for outdoor wireless deployments, this rugged bi-directional amplifier features high linear gain, integrated low noise amplification, ultra-low power consumption, and patented waterproof construction. Ideal for wireless networks, outdoor radio systems, and OEM applications requiring compact high-performance RF amplification.
Key Features
Amplification
Bi-directional 1 Watt amplifier with highly linear operation and 2 Watt (33 dBm) saturated output
HBT Technology
Utilizes Gallium Arsenide Heterojunction Bipolar Transistor (HBT) technology for high efficiency and linear gain
Low Noise Amplifier
Integrated 22 dB LNA improves receive sensitivity while maintaining low noise levels
Receive Filtering
Built-in band-pass filtering provides protection against out-of-band interference
Outdoor Design
Designed specifically for outdoor wireless deployments
Weatherproof Housing
Patented fully sealed enclosure creates a watertight installation with simple hand assembly
Compact Form Factor
World's smallest 1 Watt outdoor bi-directional amplifier in a coax-style enclosure
Power Efficiency
Consumes approximately 5 Watts during transmit and only 0.25 Watts during receive
Low Loss DC Injector
Includes DC injector with only 1.2 dB insertion loss
OEM Availability
Also available in PCB version for OEM integration
Warranty
Backed by a 2-year manufacturer warranty
Technical Data
| Parameter | Rating / Detail |
|---|---|
| Product Name | 2.4GHz 1 Watt Outdoor Amplifier (Coax Series) |
| Item Number | 24201 |
| Operating Range | 2400 - 2500 MHz |
| Operating Mode | TDD (Time Division Duplex) |
| Transmit Power | 30 dBm (1 Watt), Max Saturated Output 33 dBm (2 Watts) ±0.5 dBm |
| Transmit Gain | 22 dB |
| Transmit Input Power | 3 dBm min, 15 dBm max |
| Receive Gain | 22 dB |
| Noise Figure | 3.5 dB |
| LED Indicators | Red for Receive, Green for Transmit (visible only when cover removed) |
| Power Consumption | 40 mA Rx, 1.2 A Tx @ 6 VDC |
| Operating Temperature | -40°C to +70°C |
| Amplifier Dimensions | 1.1 in (28 mm) diameter x 4.1 in (104 mm) length |
| Amplifier Enclosure | Weatherproof machined housing |
| Amplifier Connectors | Type N Male (antenna port), Type N Female (radio port) |
| Amplifier Weight | 10 oz (283 g) |
| DC Injector Dimensions | 1.4 x 3.5 x 1.0 inches |
| DC Injector Enclosure | Machined aluminum housing with anodized finish |
| DC Injector Weight | 4.7 oz (134 g) |
| Power Supply | 110~240 VAC to 6 VDC Universal Power Supply |
| Included Accessories | Outdoor AmplifierDC InjectorUniversal Power Supply |
