Product Overview
The Ubiquiti UniFi Pro XG Aggregation Switch (USW-Pro-XG-Aggregation) is a high-performance managed L2/L3 switch designed for enterprise aggregation and high-speed data center networking. It delivers ultra-fast 1.6 Tbps switching capacity, making it ideal for demanding network infrastructures requiring reliable and scalable performance. Equipped with 32 SFP28 ports, the switch supports high-speed 10G connectivity along with advanced Layer 2 and Layer 3 features, including VLAN segmentation, static routing, and traffic management capabilities. It ensures smooth and efficient data flow across large-scale networks. Designed in a 1U rackmount form factor, the USW-Pro-XG-Aggregation features robust security controls, DHCP snooping, IGMP support, and redundant power supply capability, making it a reliable backbone solution for enterprise and ISP environments.
Key Features
Performance
High-capacity 1.6 Tbps switching performance800 Gbps throughput with 1200 Mpps forwarding rateLow-latency L2/L3 switching architecture
Connectivity
32 high-speed SFP28 portsSupports 10G networkingAdvanced port mirroring and flow control
Layer 3 Features
Supports static routing and 256,000 IPv4 routesVLAN support up to 1000 networksInterface-based VLAN and Voice VLAN support
Security Management
DHCP snooping, DHCP relay, and DHCP server supportIGMP snooping and broadcast storm controlRate limiting and loop protection
Design Build
1U rackmount enterprise-grade chassisSGCC metal housing with LCM displayRedundant power supply support for high availability
Technical Data
| Parameter | Rating / Detail |
|---|---|
| Product | Ubiquiti UniFi Pro XG Aggregation (USW-Pro-XG-Aggregation) |
| Switch Type | Managed Switch |
| Layer | L2 / L3 |
| Ports | 32 SFP28 Ports |
| Ethernet Ports | 32 RJ-45 (Basic Switching) |
| Switching Capacity | 1600 Gbps |
| Throughput | 800 Gbps |
| Forwarding Rate | 1200 Mpps |
| MAC Address Table | 32,000 Entries |
| VLAN Support | Up to 1000 VLANs |
| Static Routes | Yes (256,000 IPv4 routes) |
| Power Input | AC/DC, 100–240V |
| Power_Supply | Included, Redundant Power Support (RPS) |
| Power Consumption | Up to 200W |
| Form Factor | 1U Rackmount |
| Dimensions | 442.4 x 480 x 43.7 mm |
| Weight | 7 kg |
| Operating Temperature | -5°C to 40°C |
